DADISICK Safety Interlock Switches

DADISICK safety interlock switches offer a cost-effective solution with a compact and lightweight profile, easy installation, a wide range of contact configurations and a locking function.Used in a variety of applications where access needs to be restricted or accidental activation prevented, safety interlock switches are a mechanism that increases safety by preventing accidental or unauthorized use of a particular machine, device, or system. Depending on the specific application and requirements, safety interlock switches can take different forms. With a physical lock or a combination of buttons or switches that need to be engaged to enable or disable the device.
Monitor device status and automatically lock
Monitor device status and automatically lock
Monitor device status to prevent accidental entry
Monitor device status to prevent accidental entry
Safety switch for authorized access control
Safety switch for authorized access control
The purpose of a safety interlock switch is to reduce the risk of accidents, injuries, or damage that could result from accidental or unauthorized operation. By implementing a safety interlock switch, it ensures that only authorized personnel with the appropriate knowledge or credentials can activate or deactivate the device. For example, in machinery or industrial environments, safety interlock switches are often used to prevent accidental startup during maintenance.

DADISICK safety switch OX-D3 & OX-D2 Series

Full range of gold-plated contacts;Configured with 5 contact structures;Suitable for standard loads and micro loads;Adjustable up to 8 direction key operation holes;Adaptable to 11 types of operation keys.
DADISICK safety switch OX-D3

DADISICK safety switch OX-D3 & OX-D2 Series Technical Documents file download

  • Safety switch OX-D3 & OX-D2 Series data sheet

safety interlock switch OX-W2 Series

Safety interlock switches with locking function ensure that safety guards, doors and other protective covers remain secure until the hazardous condition is eliminated.
4 sets of gold-plated contacts;14 contact combinations;Locking force 1300N;Indicator light + emergency unlocking;Optional back unlock function.
DADISICK safety interlock switch OX-W2

DADISICK safety interlock switch OX-W2 Series Technical Documents file download

  • safety interlock switch OX-W2 Series data sheet

safety interlock switch OX-W3 Series

Safety interlock switches with locking function ensure that safety guards, doors and other protective covers remain secure until the hazardous condition is eliminated.
2 sets of gold-plated contacts;6 contact combinations;Locking force 1300N;Indicator light + emergency unlocking;Adaptable to 11 types of operation keys.
DADISICK safety interlock switch OX-W3

DADISICK safety interlock switch OX-W3 Series Technical Documents file download

  • safety interlock switch OX-W3 Series data sheet

safety interlock switch OX-W5 Series

Safety interlock switches with locking function ensure that safety guards, doors and other protective covers remain secure until the hazardous condition is eliminated.
6 sets of gold-plated contacts;4 contact combinations;Locking force 1300N;DC 24V / AC 110V;Optional front/side emergency unlocking.
DADISICK safety interlock switch OX-W5

DADISICK safety interlock switch OX-W5 Series Technical Documents file download

  • safety interlock switch OX-W5 Series data sheet

safety interlock switch OX-D6 Series

Safety interlock switches with locking function ensure that safety guards, doors and other protective covers remain secure until the hazardous condition is eliminated.
All-metal structure appearance, solid, safe and durable;It also has mechanism locking and monitoring functions;Unique coding and universal coding are optional;Independent redundant dual output: prevent safety hazards caused by failure of a single circuit;Cascade connection of door switches can reduce the number of input points.
DADISICK safety interlock switch OX-D6

DADISICK safety interlock switch OX-D6 Series Technical Documents file download

  • safety interlock switch OX-D6 Series data sheet

DADISICK Non-contact safe door switch OX-H1 Series

Non-contact zero-wear detection, shock and vibration resistance, long service life;Use code actuators to prevent human modification and effectively protect;3 sides can be sensed, suitable for L-shaped (vertical) installation;Provides universal encoding and unique encoding options;Can support cascading use of 30 door switches.
DADISICK Non-contact safety door switch OX-H1

DADISICK Non Contact Safe Door Switch OX-H1 Series Technical Documents file download

  • Non Contact Safe Door Switch OX-H1 Series Data Sheet
  • Non Contact Safe Door Switch OX-H1 Series User Manual

DADISICK Non-contact safety door switch OX-R1 Series

Adopts radio frequency induction coding technology;Strong anti-inteerence, safe and reliable;Universal coding type and single coding type optional;Sensors can be activated from 3 sides;Suppos up to 30 sensors cascaded.
DADISICK Non-contact safety door switch OX-R1

DADISICK Non-contact safety door switch OX-R1 Series Technical Documents file download

  • Non-contact safety door switch OX-R1 Series User Manual
